Charger for lead-acid batteries (Flooded, Gel, and AGM) and Li-Ion batteries (lithium iron, lithium manganese and lithium nickel cobalt manganese) (Note. 1)
AC voltage range 180 ~ 264VAC or 90 ~ 132VAC, or AC input range selected by switch
Multi-stages smart charging characteristic
Protections: Short circuit /Overload /Over voltage /Low voltage /Over temperature /Over current /Reverse polarity /Timing /Fully charged shut down /No leaking current drain out of the battery
High efficiency, Maximum efficiency can be up to 92%
Class I power, portable type.
Fan cooling with anti-dust mesh
2 color LED loading indicator
M type with Embed MCU intelligent control, RS485 and CAN2.0B communication for option, OLED display for option, it shows voltage, current, time and SOC percent
No spark DC plug design when the DC connector plugs into or unplugs from the battery
.jpg)
Features
